Ixia ThreatARMOR packs a powerful, one-two punch by protecting networks against malicious IP addresses while alleviating the burden on time-strapped IT security teams. To enhance the security performance of enterprise networks, ThreatARMOR automatically eliminates known bad IP addresses and unwanted geo-location traffic.

This enables network firewalls and intrusion prevention systems to more efficiently focus on blocking malware and identifying threats from all other IP addresses. Better yet, ThreatARMOR’s geo-blocking capabilities scrub traffic from foreign countries off networks, thereby preventing attacks from affecting network availability.

Specification

[•] 1U Security Appliance

[•] In-band or passive deployment

[•] Full line rate across all ports with blocking enabled

[•] Reporting, blocking, or fail-safe bypass operation

[•] Always-on ATI cloud security service

Management

[•] Serial console interface

[•] Front-panel LCD display and push-button controls

[•] Future option for dual management Ethernet interfaces

Physical Specifications

Size and Weight

[•] 1U high 19” chassis

[•] Dimensions: Dimensions: 16.9W x 16.7L x 1.7H (inches)

[•] Weight: 22.0lb (10 kg)

Power for ThreatARMOR 1G Appliance (AC)

[•] Dual AC power supplies

[•] Operating input voltage: 100 to 200 VAC

[•] Idle current: 0.5A @ 120VAC, 0.25A @ 240VAC

[•] Max. operating input current: 1.3A @ 120 VAC

[•] Heat/power dissipation for module at 100% traffic load: maximum 156 W / 532 BTU/hour

Operating Specifications

Operational Environment

Temperature

[•] Operating: 5°C to 40°C

[•] Storage: -20°C to 75°C

Humidity

[•] Operating: 10% to 85%, (non-condensing)
